| Information | |
|---|---|
| Platform | Workstation |
| Architecture | Blackwell 2nd-gen |
| Generation | Blackwell PRO W |
| Previous Gen | Workstation Ada |
| Interface | PCIe 5.0 x16 |
| Core | |
|---|---|
| Name | GB203 |
| Foundry | TSMC |
| Process Node | 5 nm |
| Transistors | 45600 million |
| Die Size | 378.0 mm² |
| Density | 120.6 /mm² |
| GPU Core Config | |
|---|---|
| Cores | 8960 |
| TMUs | 280 |
| ROPs | 96 |
| Tensor Cores | 280 |
| RT Cores | 70 |
| Memory | |
|---|---|
| Technology | GDDR7 |
| Size | 24 GB |
| Bus | 192 bit |
| Bandwidth | 672.0 GB/s |
| Speed | 28.0 Gbps |
| Clocks | |
|---|---|
| Base clock | 1590 MHz |
| Boost clock | 2620 MHz |
| Memory clock | 1750 MHz |
| Power | |
|---|---|
| 16-pin | 1 |
| TDP | 140 w |
| Recommended PSU | 300 w |
| Display | |
|---|---|
| DisplayPort | 4 2.1b |
| Dimensions | |
|---|---|
| Slots | 1 |
| Length | 242 mm |
| Height | 112 mm |
| Width | 20 mm |
