AMD RX 9060 XT 16GB - Prices, specifications and information

AMD RX 9060 XT 16GB

Prices, specifications and information

AMD RX 9060 XT 16GB

RX 9060 XT 16GB is a consumer-grade GPU from amd\'s RX 9000 series, built on the RDNA4 architecture using the Navi 44 chip. Equipped with 16 GB of GDDR6 memory on a 128-bit bus, it delivers 168.1 GB/s of bandwidth at 10.5 Gbps.
Lowest price
Go to store
$439.99
ASRock Radeon RX 9060 XT Challenger OC
Historical prices

Information
PlatformConsumer
ArchitectureRDNA4
GenerationRX 9000
Previous GenRX 7000
InterfacePCIe 5.0 x16
Core
NameNavi 44
FoundryTSMC
Process Node4 nm
Transistors29700 million
Die Size199.0 mm²
Density149.2 /mm²
GPU Core Config
Cores2048
TMUs128
ROPs64
RT Cores32
Memory
TechnologyGDDR6
Size16 GB
Bus128 bit
Bandwidth168.1 GB/s
Speed10.5 Gbps

Information
Platform	Consumer
Architecture	RDNA4
Generation	RX 9000
Previous Gen	RX 7000
Interface	PCIe 5.0 x16

Core
Name	Navi 44
Foundry	TSMC
Process Node	4 nm
Transistors	29700 million
Die Size	199.0 mm²
Density	149.2 /mm²

GPU Core Config
Cores	2048
TMUs	128
ROPs	64
RT Cores	32

Memory
Technology	GDDR6
Size	16 GB
Bus	128 bit
Bandwidth	168.1 GB/s
Speed	10.5 Gbps

Clocks
Base clock1700 MHz
Game Clock2530 MHz
Boost clock3130 MHz
Memory clock2518 MHz
Power
8-pin1
TDP160 w
Recommended PSU500 w
Display
DisplayPort2 2.1a
HDMI1 2.1b
HDCP2.3

Clocks
Base clock	1700 MHz
Game Clock	2530 MHz
Boost clock	3130 MHz
Memory clock	2518 MHz

Power
8-pin	1
TDP	160 w
Recommended PSU	500 w

Display
DisplayPort	2 2.1a
HDMI	1 2.1b
HDCP	2.3

Models

GPU▲	Price▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
Asus Dual Radeon RX 9060 XT DUAL-RX9060XT-16G	$479.99 Newegg	3230 MHz +3.2%	2.5	202 mm	120 mm	49 mm
Asus Prime Radeon RX 9060 XT OC Edition PRIME-RX9060XT-O16G	$650.00 TechAmerica	3310 MHz +5.8%	2.5	304 mm	126 mm	50 mm
Asus Dual Radeon RX 9060 XT White Edition DUAL-RX9060XT-16G-WHITE	$629.00 TechAmerica	3230 MHz +3.2%	2.5	202 mm	120 mm	49 mm
Asus TUF Gaming Radeon RX 9060 XT OC Edition TUF-RX9060XT-O16G-GAMING	$670.00 TechAmerica	3320 MHz +6.1%	2.5	304 mm	126 mm	50 mm
ASRock Radeon RX 9060 XT Steel Legend OC RX9060XT SL 16GO	$485.00 TechAmerica	3320 MHz +6.1%	2.6	298 mm	131 mm	51 mm
ASRock Radeon RX 9060 XT Challenger RX9060XT CL 16G	$550.00 TechAmerica	3230 MHz +3.2%	2.1	249 mm	132 mm	41 mm
ASRock Radeon RX 9060 XT Challenger OC RX9060XT CL 16GO	$439.99 Newegg	3290 MHz +5.1%	2.1	249 mm	132 mm	41 mm
Gigabyte Radeon RX 9060 XT GAMING GV-R9060XTGAMING-16GD		3230 MHz +3.2%	2	281 mm	118 mm	40 mm
Gigabyte Radeon RX 9060 XT GAMING OC GV-R9060XTGAMING OC-16GD	$459.99 Newegg	3320 MHz +6.1%	2	281 mm	118 mm	40 mm
Gigabyte Radeon RX 9060 XT GAMING OC ICE GV-R906XGAMINGOCICE-16GD	$469.99 BestBuy	3320 MHz +6.1%	2	281 mm	118 mm	40 mm
PowerColor Reaper AMD Radeon RX 9060 XT RX9060XT 16G-A	$469.99 Newegg	3230 MHz +3.2%	2	200 mm	100 mm	39 mm
PowerColor Hellhound AMD Radeon RX 9060 XT RX9060XT 16G-L/OC		3310 MHz +5.8%	2	310 mm	100 mm	40 mm
PowerColor Hellhound Spectral White AMD Radeon RX 9060 XT RX9060XT 16G-L/OC/WHITE		3310 MHz +5.8%	2	310 mm	100 mm	40 mm
XFX Mercury AMD Radeon RX 9060 XT OC White Gaming Edition RX-96TMERCW9	$529.99 BestBuy	3320 MHz +6.1%	2.7	320 mm	127 mm	53 mm
XFX Mercury AMD Radeon RX 9060XT OC Gaming Edition RX-96TMERCBA		3320 MHz +6.1%	2.7	320 mm	127 mm	53 mm
XFX Mercury AMD Radeon RX 9060 XT OC Gaming Edition RX-96TMERCB9	$509.99 BestBuy	3320 MHz +6.1%	2.7	320 mm	127 mm	53 mm
Sapphire NITRO+ AMD Radeon RX 9060 XT OC 11350-01-20G		3320 MHz +6.1%	2.8	300 mm	131 mm	55 mm
Sapphire PURE AMD Radeon RX 9060 XT OC 11350-02-20G		3290 MHz +5.1%	2.3	240 mm	124 mm	46.1 mm
Sapphire PULSE AMD Radeon RX 9060 XT OC 11350-03-20G	$449.99 Newegg	3290 MHz +5.1%	2.3	240 mm	124 mm	46.1 mm
XFX Swift AMD Radeon RX 9060 XT OC White Triple Fan Gaming Edition RX-96TS316W7	$509.99 BestBuy	3320 MHz +6.1%	2.5	290 mm	124 mm	49 mm
XFX Swift AMD Radeon RX 9060 XT OC Triple Fan Gaming Edition RX-96TS316B7	$469.99 Newegg	3320 MHz +6.1%	2.5	290 mm	124 mm	49 mm
XFX Swift AMD Radeon RX 9060XT OC Triple Fan Gaming Edition RX-96TS316BA		3320 MHz +6.1%	2.5	290 mm	124 mm	49 mm
XFX Swift AMD Radeon RX 9060 XT OC White Gaming Edition RX-96TSW16WQ		3320 MHz +6.1%	2.4	270 mm	124 mm	48 mm
XFX Swift AMD Radeon RX 9060 XT OC Gaming Edition RX-96TSW16BQ	$459.99 Newegg	3320 MHz +6.1%	2.4	270 mm	124 mm	48 mm
Acer Nitro Radeon RX 9060 XT		3230 MHz +3.2%	2
