| Information | |
|---|---|
| Platform | Consumer |
| Architecture | Ampere |
| Generation | GeForce RTX 30 |
| Previous Gen | GeForce RTX 20 |
| Next generation | GeForce RTX 40 |
| Interface | PCIe 4.0 x16 |
| Max temperature | 93 C |
| Core | |
|---|---|
| Name | GA104 |
| Foundry | Samsung |
| Process Node | 8 nm |
| Transistors | 17400 million |
| Die Size | 392.0 mm² |
| Density | 44.4 /mm² |
| GPU Core Config | |
|---|---|
| Cores | 4864 |
| TMUs | 152 |
| ROPs | 80 |
| SMs | 38 |
| Tensor Cores | 152 |
| RT Cores | 38 |
| Memory | |
|---|---|
| Technology | GDDR6 |
| Size | 8 GB |
| Bus | 256 bit |
| Bandwidth | 448.0 GB/s |
| Speed | 14.0 Gbps |
| Clocks | |
|---|---|
| Base clock | 1410 MHz |
| Boost clock | 1785 MHz 1665 MHz |
| Memory clock | 1750 MHz |
| Power | |
|---|---|
| 6-pin | 1 |
| 8-pin | 1 |
| TDP | 200 w |
| Recommended PSU | 650 w 600 w |
| Display | |
|---|---|
| DisplayPort | 2 1.4a |
| HDMI | 2 2.1 |
| HDCP | 2.3 |
| Resolution | 7680 x 4320 |
| Monitors | 4 |
| Dimensions | |
|---|---|
| Slots | 2.8 2 |
| Length | 296 mm 242 mm |
| Height | 117 mm 112 mm |
| Width | 56 mm 40 mm |
| GPU▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 1665 MHz | 2 | 247 mm | 120 mm | 40 mm | ||
| 1860 MHz +11.7% | 2.9 | 318.5 mm | 140.1 mm | 57.8 mm | ||
| 1665 MHz | 2.9 | 318.5 mm | 140.1 mm | 57.8 mm | ||
| 1665 MHz | 2.9 | 318.5 mm | 140.1 mm | 57.8 mm | ||
| 1860 MHz +11.7% | 2.9 | 318.5 mm | 140.1 mm | 57.8 mm | ||
| 1695 MHz +1.8% | 2 | 222.1 mm | 115.6 mm | 38.2 mm | ||
| 1800 MHz +8.1% | 2.7 | 294 mm | 112 mm | |||
| 1665 MHz | 2 | 242 mm | 112 mm | 40 mm | ||
| 1740 MHz +4.5% | 2.7 | 269 mm | 136 mm | 52 mm | ||
| 1710 MHz +2.7% | 2 | 201.8 mm | 110 mm | 40 mm | ||
| 1785 MHz +7.2% | 2.8 | 296 mm | 117 mm | 56 mm | ||
| 1740 MHz +4.5% | 2.1 | 282 mm | 117 mm | 41 mm | ||
| 1665 MHz | 2.1 | 245 mm | 112 mm | 41.5 mm |
