| Information | |
|---|---|
| Platform | Consumer |
| Architecture | Turing |
| Generation | GeForce RTX 20 |
| Previous Gen | GeForce 10 |
| Next generation | GeForce RTX 30 |
| Interface | PCIe 3.0 x16 |
| Max temperature | 89 C |
| Core | |
|---|---|
| Name | TU106 |
| Foundry | TSMC |
| Process Node | 12 nm |
| Transistors | 10800 million |
| Die Size | 445.0 mm² |
| Density | 24.3 /mm² |
| GPU Core Config | |
|---|---|
| Cores | 2176 |
| TMUs | 136 |
| ROPs | 64 |
| Tensor Cores | 272 |
| RT Cores | 34 |
| Memory | |
|---|---|
| Technology | GDDR6 |
| Size | 8 GB |
| Bus | 256 bit |
| Bandwidth | 448.0 GB/s |
| Speed | 14.0 Gbps |
| Clocks | |
|---|---|
| Base clock | 1470 MHz |
| Boost clock | 1650 MHz |
| Memory clock | 1750 MHz |
| Power | |
|---|---|
| 8-pin | 1 |
| TDP | 175 w |
| Recommended PSU | 450 w 550 w |
| Display | |
|---|---|
| DisplayPort | 2 1.4a |
| HDMI | 1 2.0 |
| DVI | 1 |
| USB Type-C | 1 |
| Resolution | 7680 x 4320 |
| Monitors | 4 |
| Dimensions | |
|---|---|
| Slots | 2 |
| Length | 229 mm |
| Height | 113 mm |
| Width | 35 mm |
