NVIDIA RTX 2060 Super - Prices, specifications and information

NVIDIA RTX 2060 Super

Prices, specifications and information

GPU

Featuring 240+ GPU-models — And growing.

GPUs > NVIDIA RTX 2060 Super

NVIDIA RTX 2060 Super

RTX 2060 Super is a consumer-grade GPU from nvidia\'s GeForce RTX 20 series, built on the Turing architecture using the TU106 chip. Equipped with 8 GB of GDDR6 memory on a 256-bit bus, it delivers 448.0 GB/s of bandwidth at 14.0 Gbps.

Information
PlatformConsumer
ArchitectureTuring
GenerationGeForce RTX 20
Previous GenGeForce 10
Next generationGeForce RTX 30
InterfacePCIe 3.0 x16
Max temperature89 C
Core
NameTU106
FoundryTSMC
Process Node12 nm
Transistors10800 million
Die Size445.0 mm²
Density24.3 /mm²
GPU Core Config
Cores2176
TMUs136
ROPs64
Tensor Cores272
RT Cores34
Memory
TechnologyGDDR6
Size8 GB
Bus256 bit
Bandwidth448.0 GB/s
Speed14.0 Gbps

Information
Platform	Consumer
Architecture	Turing
Generation	GeForce RTX 20
Previous Gen	GeForce 10
Next generation	GeForce RTX 30
Interface	PCIe 3.0 x16
Max temperature	89 C

Core
Name	TU106
Foundry	TSMC
Process Node	12 nm
Transistors	10800 million
Die Size	445.0 mm²
Density	24.3 /mm²

GPU Core Config
Cores	2176
TMUs	136
ROPs	64
Tensor Cores	272
RT Cores	34

Memory
Technology	GDDR6
Size	8 GB
Bus	256 bit
Bandwidth	448.0 GB/s
Speed	14.0 Gbps

Clocks
Base clock1470 MHz
Boost clock1650 MHz
Memory clock1750 MHz
Power
8-pin1
TDP175 w
Recommended PSU550 w
Display
DisplayPort1
HDMI1
DVI1
Resolution7680 x 4320
Monitors4
Dimensions
Slots2
Length229 mm
Height113 mm
Width35 mm

Clocks
Base clock	1470 MHz
Boost clock	1650 MHz
Memory clock	1750 MHz

Power
8-pin	1
TDP	175 w
Recommended PSU	550 w

Display
DisplayPort	1
HDMI	1
DVI	1
Resolution	7680 x 4320
Monitors	4

Dimensions
Slots	2
Length	229 mm
Height	113 mm
Width	35 mm

Models

GPU▲	Price▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
Gainward GeForce RTX 2060 Super Ghost NE6206S018P2-1160X-1		1650 MHz
NVIDIA RTX 2060 Super Founders Edition		1650 MHz	2	229 mm	113 mm	35 mm
