| Platform | Consumer |
| Architecture | Turing |
| Generation | GeForce 16 |
| Previous Gen | GeForce 10 |
| Next generation | GeForce RTX 20 |
| Interface | PCIe 3.0 x16 |
| Name | TU117 |
| Foundry | TSMC |
| Process Node | 12 nm |
| Transistors | 4700 million |
| Die Size | 200.0 mm² |
| Density | 23.5 /mm² |
| Cores | 512 |
| TMUs | 32 |
| ROPs | 16 |
| Technology | GDDR6 |
| Size | 4 GB |
| Bus | 64 bit |
| Bandwidth | 96.0 GB/s |
| Speed | 12.0 Gbps |
| Base clock | 1740 MHz |
| Boost clock | 1845 MHz 1785 MHz |
| Memory clock | 1500 MHz |
| 6-pin | 1 |
| TDP | 75 w |
| Recommended PSU | 300 w |
| DisplayPort | 1 1.4a |
| HDMI | 1 2.0b |
| HDCP | 2.2 |
| DVI-D DL | 1 |
| Slots | 2.3 2 |
| Length | 204.5 mm 145 mm |
| Height | 124.9 mm 111 mm |
| Width | 45.6 mm 40 mm |
| GPUs▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| $186.00 | 1815 MHz +1.7% | 2 | 174 mm | 126 mm | 39 mm | |
| $196.00 | 1845 MHz +3.4% | 2.3 | 204.5 mm | 124.9 mm | 45.6 mm |
