| Information | |
|---|---|
| Platform | Workstation |
| Architecture | Kepler 2.0 |
| Generation | GeForce 700 |
| Previous Gen | GeForce 600 |
| Next generation | GeForce 900 |
| Interface | PCIe 2.0 x8 |
| Core | |
|---|---|
| Name | GK208B |
| Foundry | TSMC |
| Process Node | 28 nm |
| Transistors | 1020 million |
| Die Size | 87.0 mm² |
| Density | 11.7 /mm² |
| GPU Core Config | |
|---|---|
| Cores | 384 |
| TMUs | 32 |
| ROPs | 8 |
| Memory | |
|---|---|
| Technology | GDDR5 |
| Size | 4 GB 2 GB |
| Bus | 64 bit |
| Bandwidth | 40.1 GB/s |
| Speed | 5.0 Gbps |
| Clocks | |
|---|---|
| Base clock | 902 MHz |
| Boost clock | 927 MHz |
| Memory clock | 1252 MHz |
| Power | |
|---|---|
| TDP | 49 w |
| Recommended PSU | 300 w |
| Display | |
|---|---|
| HDMI | 1 |
| DVI-D DL | 1 |
| VGA | 1 |
| Resolution | 3840 x 2160 |
| Dimensions | |
|---|---|
| Slots | 2 |
| Length | 145.8 mm |
| Height | 111.1 mm |
| Width | 40 mm |
| GPU▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 927 MHz | 1 | 148 mm | 105 mm | 18 mm | ||
| 927 MHz | 2 | 145.8 mm | 111.1 mm | 40 mm | ||
| 927 MHz | 1 | 167 mm | 69 mm | 17 mm |
