Intel Arc Pro B50 - Prices, specifications and information

Intel Arc Pro B50

Prices, specifications and information

GPU

Featuring 240+ GPU-models — And growing.

GPUs > Intel Arc Pro B50 > Intel Arc Pro B50

Intel Arc Pro B50
33P6PEB0BB

Information
PlatformWorkstation
ArchitectureBattlemage
GenerationArc B
Previous GenArc A
InterfacePCIe 5.0 x8
Core
NameBMG-G21
FoundryTSMC
Process Node5 nm
Transistors19600 million
Die Size272.0 mm²
Density72.1 /mm²
GPU Core Config
Cores2048
TMUs128
ROPs16
RT Cores16
Memory
TechnologyGDDR6
Size16 GB
Bus128 bit
Bandwidth224.0 GB/s
Speed14.0 Gbps

Information
Platform	Workstation
Architecture	Battlemage
Generation	Arc B
Previous Gen	Arc A
Interface	PCIe 5.0 x8

Core
Name	BMG-G21
Foundry	TSMC
Process Node	5 nm
Transistors	19600 million
Die Size	272.0 mm²
Density	72.1 /mm²

GPU Core Config
Cores	2048
TMUs	128
ROPs	16
RT Cores	16

Memory
Technology	GDDR6
Size	16 GB
Bus	128 bit
Bandwidth	224.0 GB/s
Speed	14.0 Gbps

Clocks
Base clock1700 MHz
Boost clock2600 MHz
Memory clock1750 MHz
Power
TDP70 w
Recommended PSU280 w 250 w
Display
Mini DisplayPort4
Dimensions
Slots2
Length168 mm 167 mm
Height69 mm
Width40 mm
Weight330 g

Clocks
Base clock	1700 MHz
Boost clock	2600 MHz
Memory clock	1750 MHz

Power
TDP	70 w
Recommended PSU	280 w 250 w

Display
Mini DisplayPort	4

Dimensions
Slots	2
Length	168 mm 167 mm
Height	69 mm
Width	40 mm
Weight	330 g

Models

GPU▲	Price▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
Intel Arc Pro B50 33P6PEB0BB		2600 MHz	2	168 mm	69 mm	40 mm
