| Core | |
|---|---|
| Name | Navi 31 |
| Foundry | TSMC |
| Process Node | 5 nm |
| Transistors | 57700 million |
| Die Size | 529.0 mm² |
| Density | 109.1 /mm² |
| GPU Core Config | |
|---|---|
| Cores | 6144 |
| Compute Units | 96 |
| TMUs | 384 |
| ROPs | 192 |
| RT Cores | 96 |
| Memory | |
|---|---|
| Technology | GDDR6 |
| Size | 24 GB |
| Bus | 384 bit |
| Infinity Cache | 96 MB |
| Bandwidth | 960.0 GB/s |
| Speed | 20.0 Gbps |
| Clocks | |
|---|---|
| Base clock | 1855 MHz |
| Game Clock | 2455 MHz |
| Boost clock | 2615 MHz 2499 MHz |
| Memory clock | 2500 MHz |
| Power | |
|---|---|
| 8-pin | 3 |
| TDP | 355 w |
| Recommended PSU | 1000 w 750 w |
| Display | |
|---|---|
| DisplayPort | 3 2.1 |
| HDMI | 1 2.1 |
| Dimensions | |
|---|---|
| Slots | 2.9 |
| Length | 330 mm |
| Height | 140 mm |
| Width | 57.6 mm |
| Weight | 1550 g |
| GPU▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 2680 MHz +7.2% | 3.6 | 320 mm | 135.8 mm | 71.6 mm | ||
| 2615 MHz +4.6% | 3.7 | 352.9 mm | 158.2 mm | 72.6 mm | ||
| 2525 MHz +1.0% | 3.1 | 320 mm | 118.5 mm | 62 mm | ||
| 2680 MHz +7.2% | 3.1 | 345 mm | 140 mm | 61 mm | ||
| 2615 MHz +4.6% | 2.9 | 330 mm | 140 mm | 57.6 mm | ||
| 2615 MHz +4.6% | 2.9 | 344 mm | 128 mm | 57 mm | ||
| 2525 MHz +1.0% | 2.7 | 313 mm | 133.8 mm | 52.7 mm |
