| Information | |
|---|---|
| Platform | Workstation |
| Architecture | RDNA4 |
| Interface | PCIe 5.0 x16 |
| Core | |
|---|---|
| Name | Navi 48 |
| Foundry | TSMC |
| Process Node | 4 nm |
| Transistors | 53900 million |
| Die Size | 357.0 mm² |
| Density | 151.0 /mm² |
| GPU Core Config | |
|---|---|
| Cores | 4096 |
| TMUs | 256 |
| ROPs | 128 |
| Memory | |
|---|---|
| Technology | GDDR6 |
| Size | 32 GB |
| Bus | 256 bit |
| Bandwidth | 644.6 GB/s |
| Speed | 20.1 Gbps |
| Clocks | |
|---|---|
| Base clock | 1660 MHz |
| Game Clock | 2350 MHz |
| Boost clock | 2920 MHz |
| Memory clock | 2518 MHz |
| Power | |
|---|---|
| 16-pin | 1 |
| TDP | 300 w |
| Recommended PSU | 750 w 700 w |
| Display | |
|---|---|
| DisplayPort | 4 2.1a |
| Resolution | 7680 x 4320 |
| Dimensions | |
|---|---|
| Slots | 2 |
| Length | 271 mm 267 mm |
| Height | 112 mm 111 mm |
| Width | 39 mm 40 mm |
| GPU▲ | Price▲ | Boost clock▲ | Slots▲ | Length▲ | Height▲ | Width▲ |
|---|---|---|---|---|---|---|
| 2940 MHz +0.7% | 2 | 266.7 mm | 111.1 mm | 40 mm | ||
| 2920 MHz | 2 | 267 mm | 111 mm | 40 mm | ||
| 2920 MHz | 2 | 271 mm | 112 mm | 39 mm | ||
| 2920 MHz | 2 | 266.7 mm | 111.2 mm | 40 mm | ||
| 2920 MHz | 2 | 266.7 mm | 111 mm | 39 mm |
