Intel Arc A770

Arc A770 is a consumer-grade GPU from Intel\'s Arc A series, built on the Alchemist architecture using the DG2-512 chip. Equipped with 16 GB of GDDR6 memory on a 256-bit bus, it delivers 1024.0 GB/s of bandwidth at 32.0 Gbps.

Information
PlatformConsumer
ArchitectureAlchemist
GenerationArc A
Next generationArc B
InterfacePCIe 4.0 x16
Core
NameDG2-512
FoundryTSMC
Process Node6 nm
Transistors21700 million
Die Size406.0 mm²
Density53.4 /mm²
GPU Core Config
Cores4096
TMUs256
ROPs128
Tensor Cores512
RT Cores32
Memory
TechnologyGDDR6
Size16 GB
Bus256 bit
Bandwidth1,024.0 GB/s
Speed32.0 Gbps

Information
Platform	Consumer
Architecture	Alchemist
Generation	Arc A
Next generation	Arc B
Interface	PCIe 4.0 x16

Core
Name	DG2-512
Foundry	TSMC
Process Node	6 nm
Transistors	21700 million
Die Size	406.0 mm²
Density	53.4 /mm²

GPU Core Config
Cores	4096
TMUs	256
ROPs	128
Tensor Cores	512
RT Cores	32

Memory
Technology	GDDR6
Size	16 GB
Bus	256 bit
Bandwidth	1,024.0 GB/s
Speed	32.0 Gbps

Clocks
Base clock2100 MHz
Boost clock2400 MHz
Memory clock2000 MHz
Power
6-pin1
8-pin1
TDP225 w
Recommended PSU550 w
Display

Clocks
Base clock	2100 MHz
Boost clock	2400 MHz
Memory clock	2000 MHz

Power
6-pin	1
8-pin	1
TDP	225 w
Recommended PSU	550 w

Models

GPU▲	Price▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
ASRock Intel Arc A770 Challenger SE OC A770 CL SE 16GO		MHz
