NVIDIA RTX A2000 - Prices, specifications and information

NVIDIA RTX A2000

Prices, specifications and information

GPU

Featuring 240+ GPU-models — And growing.

GPUs > NVIDIA RTX A2000

NVIDIA RTX A2000

RTX A2000 is a workstation-grade GPU from NVIDIA\'s GeForce RTX 30 series, built on the Ampere architecture using the GA106 chip. Equipped with 6 GB of GDDR6 memory on a 192-bit bus, it delivers 288.0 GB/s of bandwidth at 12.0 Gbps.

Information
PlatformWorkstation
ArchitectureAmpere
GenerationGeForce RTX 30
Previous GenGeForce RTX 20
Next generationGeForce RTX 40
Core
NameGA106
FoundrySamsung
Process Node8 nm
Transistors12000 million
Die Size276.0 mm²
Density43.5 /mm²
GPU Core Config
Cores3328
TMUs104
ROPs48
Tensor Cores104
RT Cores26
Memory
TechnologyGDDR6
Size6 GB
Bus192 bit
Bandwidth288.0 GB/s
Speed12.0 Gbps

Information
Platform	Workstation
Architecture	Ampere
Generation	GeForce RTX 30
Previous Gen	GeForce RTX 20
Next generation	GeForce RTX 40

Core
Name	GA106
Foundry	Samsung
Process Node	8 nm
Transistors	12000 million
Die Size	276.0 mm²
Density	43.5 /mm²

GPU Core Config
Cores	3328
TMUs	104
ROPs	48
Tensor Cores	104
RT Cores	26

Memory
Technology	GDDR6
Size	6 GB
Bus	192 bit
Bandwidth	288.0 GB/s
Speed	12.0 Gbps

Clocks
Base clock562 MHz
Boost clock1200 MHz
Memory clock1500 MHz
Power
TDP70 w
Recommended PSU500 w
Display
Mini DisplayPort4
Dimensions
Slots2

Clocks
Base clock	562 MHz
Boost clock	1200 MHz
Memory clock	1500 MHz

Power
TDP	70 w
Recommended PSU	500 w

Display
Mini DisplayPort	4

Dimensions
Slots	2

Models

GPU▲	Price▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
PNY RTX A2000 VCNRTXA2000-PB		1200 MHz
