NVIDIA RTX 4000 Ada SFF

RTX 4000 Ada SFF is a workstation-grade GPU from NVIDIA\'s GeForce RTX 40 series, built on the Ada Lovelace architecture using the AD104 chip. Equipped with 20 GB of GDDR6 memory on a 160-bit bus, it delivers 280.0 GB/s of bandwidth at 14.0 Gbps.

Information
PlatformWorkstation
ArchitectureAda Lovelace
GenerationGeForce RTX 40
Previous GenGeForce RTX 30
Next generationGeForce RTX 50
InterfacePCIe 4.0 x16
Core
NameAD104
FoundryTSMC
Process Node5 nm
Transistors35800 million
Die Size294.0 mm²
Density121.8 /mm²
GPU Core Config
Cores6144
TMUs192
ROPs64
SMs48
RT Cores48
Memory
TechnologyGDDR6
Size20 GB
Bus160 bit
Bandwidth280.0 GB/s
Speed14.0 Gbps

Information
Platform	Workstation
Architecture	Ada Lovelace
Generation	GeForce RTX 40
Previous Gen	GeForce RTX 30
Next generation	GeForce RTX 50
Interface	PCIe 4.0 x16

Core
Name	AD104
Foundry	TSMC
Process Node	5 nm
Transistors	35800 million
Die Size	294.0 mm²
Density	121.8 /mm²

GPU Core Config
Cores	6144
TMUs	192
ROPs	64
SMs	48
RT Cores	48

Memory
Technology	GDDR6
Size	20 GB
Bus	160 bit
Bandwidth	280.0 GB/s
Speed	14.0 Gbps

Clocks
Base clock720 MHz
Boost clock1560 MHz
Memory clock1750 MHz
Power
TDP70 w
Recommended PSU400 w
Display
Mini DisplayPort4
Dimensions
Slots2
Length168 mm
Height69 mm
Width40 mm

Clocks
Base clock	720 MHz
Boost clock	1560 MHz
Memory clock	1750 MHz

Power
TDP	70 w
Recommended PSU	400 w

Display
Mini DisplayPort	4

Dimensions
Slots	2
Length	168 mm
Height	69 mm
Width	40 mm

Models

GPU▲	Boost clock▲	Slots▲	Length▲	Height▲	Width▲
PNY RTX 4000 SFF Ada Generation VCNRTX4000ADALP-PB	1560 MHz	2	168 mm	69 mm	40 mm
PNY RTX 4000 SFF Ada Generation Bulk VCNRTX4000ADALP-SB	1560 MHz
NVIDIA RTX 4000 Ada SFF 900-5G192-2571-000	1560 MHz
NVIDIA RTX 4000 Ada SFF Bulk 900-5G192-2270-000	1560 MHz
PNY RTX 4000 SFF Ada Generation LP VCNRTX4000ADALP-PL	1560 MHz
